Description
Motorola MVME2400-0331
Technical Specifications
- Base Platform: MVME2400 Series (PowerPC Architecture).
- Custom Configuration: Specific DRAM capacity and Flash layout.
- Firmware: Pre-installed or supports a specific PPCBug firmware version.
Functional Features
- Provides a plug-and-play customized hardware solution.
- Reduces customer time for hardware configuration and testing.
- Maintains software and mechanical compatibility with the standard MVME2400 series.
Application Scenarios
Dedicated to specific defense projects, aerospace test benches, or customized industrial control cabinets.
Performance Parameters
- Performance matches the standard MVME2400 platform but optimized for specific applications.
- Deterministic real-time response capabilities.
Material Composition
Industrial-grade PCB with oxidation-resistant gold-plated edge connectors.
Structural Characteristics
Standard 6U VME size; front panel labeling includes specific customer or configuration codes.
Working Principle
Identical to the standard MVME2400, achieving system control and data exchange through the PowerPC core and VME/PCI bridge chips.
Installation Requirements
- Configure jumpers strictly according to the specific hardware manual for this model.
- Confirm firmware compatibility with the existing system.
Usage Precautions
- Ensure the complete model number (including suffix) matches exactly when replacing.
- Do not alter on-board jumpers arbitrarily to avoid corrupting the custom configuration.
