Description
Motorola MVME258KB
Technical Specifications
- Microprocessor: PowerPC 604e.
- Clock Speed: 300 MHz.
- Memory: 256 MB ECC DRAM.
- Storage: 8 MB Flash.
Functional Features
- Custom I/O: Tailored peripheral support for specific application requirements.
- Enhanced Reliability: Extended temperature range components and conformal coating options.
- System Integrity: Hardware watchdog and battery-backed RTC.
- Debug Support: Onboard diagnostic monitor.
Application Scenarios
Used in harsh environment industrial control, military command systems, and specialized test equipment.
Performance Parameters
- VME Transfer: A24/A32 addressing, D32/D16 transfers.
- Network: 10/100Base-T Ethernet.
- Serial: Multiple high-speed serial ports.
Material Composition
Ruggedized industrial PCB with conformal coating and high-reliability connectors.
Structural Characteristics
6U VME form factor with front panel status indicators and manual controls.
Working Principle
Operates identically to the standard MVME258, with firmware configured for specific I/O mappings and system parameters.
Installation Requirements
Verify environmental specifications match the application. Ensure proper chassis grounding.
Usage Precautions
Follow all handling guidelines for conformal-coated boards. Do not operate outside specified temperature ranges.
