Description
Motorola MVME259
Technical Specifications
- Microprocessor: PowerPC 604e.
- Clock Speed: 350 MHz.
- Memory: 512 MB DRAM with ECC.
- Storage: 16 MB Flash, 512 KB NVRAM.
Functional Features
- Top-Tier Performance: 350 MHz 604e core provides exceptional processing power.
- Large Memory Capacity: 512 MB ECC RAM handles complex applications.
- Full System Controller: VME arbitration, interrupt handling, DMA.
- Rich Peripheral Set: Dual Ethernet, multi-serial, SCSI, USB.
Application Scenarios
Ideal for aerospace testing, radar/sonar, nuclear instrumentation, and high-end industrial automation.
Performance Parameters
- VME Bus: A24/A32 addressing, D32/D16 transfers.
- Network: Dual 10/100Base-T Ethernet.
- Timers: Multiple system timers and watchdog.
Material Composition
Multi-layer industrial PCB with high-reliability components.
Structural Characteristics
Standard 6U Eurocard VME size with front panel LEDs and switches.
Working Principle
The system boots from Flash, performs POST, and loads the OS. The processor communicates via VME bus for external I/O.
Installation Requirements
Insert into 6U VME chassis. Align P1/P2 connectors and lock securely.
Usage Precautions
Never hot-swap. Check NVRAM battery regularly. Verify firmware compatibility.
