Motorola MVME2603-1161C
Technical Specifications
- Processor: PowerPC 603 enhanced microprocessor.
- Memory: Supports high-capacity ECC DRAM and Flash storage.
- Interfaces: Supports VME64 extensions providing a 16-bit SCSI bus.
Functional Features
- VME64 Support: SCSI bus width extends to 16 bits when used in VME64 backplane systems.
- SCSI Termination: Supports SCSI bus termination and TERMPWR supply via transition modules.
- System Control: Features a global control/status register for interprocessor communications.
Application Scenarios
Applicable in large telecommunications switches, high-speed data acquisition systems, industrial automation main control units, and medical equipment.
Performance Parameters
- Processor Clock: Supports multiple clock speed options.
- Data Transfer: Supports A16/A24/A32 addressing and D8/D16/D32/D64 block transfers.
Material Composition
Constructed with premium electronic components and multi-layer industrial-grade PCB ensuring long-term stable operation.
Structural Characteristics
Standard Double-high VME board with rich external interfaces on the front panel.
Operating Principle
Leverages the high bandwidth of VME64 extensions combined with PowerPC 603 processing power to achieve rapid throughput of massive data.
Installation Requirements
Ensure the VME backplane supports the VME64 standard. Install SCSI termination resistors correctly.
Usage Precautions
System integrators must ensure proper SCSI bus termination at both ends. In MVME761 I/O mode, termination resistors can be enabled or disabled via jumpers.
