Motorola MVME2700-3251
Technical Specifications
- Microprocessor: PowerPC 750 at 266 MHz.
- Memory: 256MB ECC DRAM via RAM200.
- Storage: 8MB onboard Flash, 1MB slot-in Flash.
- Power: Standard VME power rails.
Functional Features
- Large Memory Pool: 256MB ECC DRAM for extensive buffering.
- High-Speed I/O: Ethernet and SCSI with DMA.
- System Control: VMEbus system controller functionality.
- Real-Time Capabilities: Programmable timers and watchdog.
Application Scenarios
- Database Servers: Industrial historian and data logging.
- Vision Systems: Machine vision processing.
- Process Control: Large-scale DCS nodes.
Performance Parameters
- Operating Temperature: 0°C to 55°C with forced-air cooling.
- Storage Temperature: -40°C to +85°C.
- Humidity: 5% to 90% non-condensing.
- Bus Performance: High-speed DMA transfers.
Material Composition
High-density PCB, ECC memory modules, and lithium backup battery.
Structural Characteristics
- Form Factor: Double-high 6U VMEbus.
- Dimensions: Standard VME 6U mechanical footprint.
Working Principle
The PowerPC processor accesses the 256MB ECC memory pool via the RAM200 module, utilizing DMA channels to offload data transfers from the CPU.
Installation Requirements
- Install in a 6U VME chassis with forced-air cooling.
- Ensure adequate clearance for heat dissipation from memory modules.
Usage Precautions
- Handle with ESD protection.
- The higher memory density requires careful handling.
- Verify power supply can handle the increased load.
