Motorola MVME328XT-2

Motorola MVME328XT-2

Product Introduction
The Motorola MVME328XT-2 is an embedded computer system module specifically engineered for harsh industrial environments. Built upon Motorola’s classic VMEbus architecture, it delivers exceptional data processing and system control capabilities, serving as a reliable core for industrial automation, traffic control, and high-reliability computing platforms.

Request Quote
Category:

Description

Motorola MVME328XT-2

Technical Specifications

  • Processor Architecture: Powered by the Motorola 68040 microprocessor with a clock speed of up to 33MHz.
  • Memory Configuration: Standard 16MB DRAM, expandable up to 128MB.
  • Storage System: Built-in 8MB flash memory, supporting expansion to 16MB or 32MB, with compatibility for IDE hard drives and floppy drives.
  • Bus Interface: Provides standard VMEbus interface and external bus interface.

Functional Features

  • High-Speed Data Processing: The high clock speed and advanced cache technology of the 68040 processor ensure outstanding real-time processing performance.
  • Rich I/O Interfaces: Equipped with 2 RS-232 serial interfaces, 1 10/100Mbps Ethernet interface, 2 USB 1.1 interfaces, 1 parallel interface, and 1 standard VGA display interface.
  • Real-Time OS Support: Fully compatible with mainstream real-time operating systems such as VxWorks, QNX, and Linux, providing high flexibility.

Application Scenarios

  • Industrial Automation: Functions as the core computing unit for industrial control systems, PLCs, and SCADA systems.
  • Traffic and Medical: Applied in traffic signal control systems, vehicle monitoring, and medical imaging equipment.
  • Aerospace and Military: Widely used in military computing platforms and aerospace sectors due to its high reliability and wide-temperature environmental adaptability.

Performance Parameters

  • Network Communication: Supports TCP/IP protocol with Ethernet transmission rates reaching 10/100Mbps.
  • Serial Port Speed: RS-232 interfaces support data transmission rates up to 115.2Kbps.
  • Environmental Tolerance: Operating temperature ranges from 0°C to 60°C, with a storage temperature range of -40°C to 85°C.

Material Composition
Manufactured using industrial-grade high-reliability electronic components, featuring a sturdy metal front panel and a multi-layer printed circuit board (PCB) with high flame-retardant ratings.

Structural Characteristics

  • Physical Dimensions: Compact design measuring 160mm x 100mm x 25mm.
  • Weight: Approximately 0.5kg, making it ideal for high-density chassis installation.
  • Installation Method: Supports field installation and standard VME rack mounting.
