Description
Motorola MVME55006E-0163
Technical Specifications:
- Brand: Motorola
- Model: MVME55006E-0163
- Product Series: MVME5500 Series
- Bus Architecture: VMEbus / PCI Local Bus
Functional Features:
- Ultimate Performance: Utilizes an advanced processor architecture to deliver superior computational throughput.
- High Scalability: Supports PMC expansion modules to meet diverse I/O and specialized processing requirements.
- Large Memory Capacity: Supports high-capacity ECC SDRAM to satisfy data-intensive application demands.
Application Scenarios:
Ideal for radar signal processing, advanced network routing, complex industrial process control, medical imaging, and high-end test and measurement equipment.
Performance Parameters:
- Extremely high clock speeds and memory bandwidth.
- Supports high-speed PCI-X expansion and Gigabit Ethernet communication.
Material Composition:
Features multi-layer high-speed PCB design to minimize signal interference and attenuation, ensuring high-frequency signal integrity.
Structural Characteristics:
Rugged metal front panel equipped with status indicator LEDs, a reset button, and rich front-panel I/O interfaces.
Working Principle:
Utilizes high-frequency processors for parallel task processing, achieving high-speed data throughput via high-speed local buses and VME interfaces to coordinate with external devices.
Installation Requirements:
Due to higher power consumption, ensure the chassis has sufficient forced-air cooling capabilities and correctly configure VME termination resistors.
Usage Precautions:
Pay close attention to module spacing for thermal dissipation. Always back up configurations before upgrading firmware. Hot-swapping is strictly prohibited.
