Description
Motorola MVME712-102
Technical Specifications
- Module Type: VME P2 Transition Module.
- Signal Routing: Custom pin mapping for specific OEM applications.
- Compatibility: Fully compatible with MVME5100 IPMC mode.
Functional Features
- Provides customized front-panel I/O solutions.
- Routes Ethernet, serial communication, or SCSI signals to external interfaces.
- Offers electrical isolation and signal conditioning.
Application Scenarios
Deployed in defense, aerospace, and heavy industrial automation projects requiring specific front-panel interface layouts.
Performance Parameters
- Excellent Electromagnetic Interference (EMI) immunity.
- Supports high-frequency signal transmission without significant attenuation.
Material Composition
Manufactured with flame-retardant industrial materials; connector contacts feature special plating to enhance oxidation resistance.
Structural Characteristics
Standard 6U VME transition board dimensions with custom front-panel cutout layouts to accommodate specific connector types.
Working Principle
Functions as a passive or active signal routing board, transferring electrical signals from the P2 bus to front-panel interfaces, potentially utilizing signal buffers to enhance drive capability.
Installation Requirements
- Ensure the chassis backplane P2 slot is free of debris.
- Fasten mounting screws in a diagonal pattern to ensure even pressure distribution.
Usage Precautions
- Confirm the -102 pinout definition is compatible with the current system.
- Avoid excessive bending of external cables connected to the transition module.
