Description
Motorola MVME712-104
Technical Specifications
- Module Type: VME P2 Transition Module.
- Interface Configuration: 104-specific pin mapping.
- Bus Support: Compatible with VME64 extension connectors.
Functional Features
- Simplifies part number maintenance and technical expertise requirements.
- Backward compatible with MVME2300/MVME2400 PMC modes.
- Provides stable signal grounding and power distribution.
Application Scenarios
Applicable in semiconductor manufacturing equipment, medical imaging systems, and complex industrial process control systems.
Performance Parameters
- Operating temperature range matches the host processor module.
- Signal integrity fully complies with VME bus specifications.
Material Composition
High-Tg PCB substrate ensures no deformation or delamination occurs in high-temperature environments.
Structural Characteristics
Precision-machined metal mounting brackets ensure the module remains secure in high-vibration environments.
Working Principle
Receives P2 signals from the backplane and routes them through carefully designed trace topologies, separating high-speed differential signals from low-speed control signals to minimize crosstalk.
Installation Requirements
- Wear an anti-static wrist strap during installation.
- Ensure no foreign objects are trapped between the transition module and the processor board.
Usage Precautions
- Strictly prohibit hot-plugging this module.
- Periodically inspect connector pins for oxidation or bending.
