Description
MTL 8206-TI-IS
Technical Specifications:
- Brand: MTL (Eaton)
- Model: 8206-TI-IS
- Product Type: Intrinsically Safe Thermocouple Input
- Sensor Type: Thermocouple (TC)
Functional Features:
- Intrinsic Safety: Protects hazardous area thermocouples from excessive energy.
- Cold Junction Compensation: Built-in CJC for accurate temperature measurement.
- Signal Conversion: Converts thermocouple millivolt signals to standardized 4-20mA outputs.
Application Scenarios:
Used in refineries, chemical reactors, and offshore platforms where precise temperature monitoring is required in explosive environments.
Performance Parameters:
- Measurement Accuracy: High-precision thermocouple signal conditioning.
- Safety Integrity: Certified for use in Zone 0/1/2 hazardous areas.
Material Composition:
IS-certified electronic components in a robust, flame-retardant housing.
Structural Features:
DIN rail mountable with spring-clamp or screw terminals for secure thermocouple wire connections.
Working Principle:
Receives low-energy thermocouple signals, applies cold junction compensation and linearization, and transmits a safe, isolated 4-20mA signal to the control system.
Installation Requirements:
Install in a certified safe area panel. Use approved IS thermocouple extension cables for field connections.
Usage Precautions:
Ensure proper thermocouple type configuration. Verify that all field wiring complies with intrinsic safety installation standards.
