Description
OMRON CS1W-MAD44
Technical Specifications:
- Brand: OMRON
- Model: CS1W-MAD44
- Product Type: Analog I/O Unit
- Compatible System: CS1 Series PLC
- Number of Inputs: 4 channels
- Number of Outputs: 4 channels
- Input Signal Range:
- Voltage: 1 to 5 V, 0 to 5 V, 0 to 10 V, -10 to 10 V
- Current: 4 to 20 mA
- Output Signal Range:
- Voltage: 1 to 5 V, 0 to 5 V, 0 to 10 V, -10 to 10 V
- Resolution: 1/4000 (12-bit)
- Conversion Speed: 1 ms/point
- Accuracy: ±0.2% of full scale (Input), ±0.3% (Output)
- Power Consumption: 200 mA at 5 VDC
- Dimensions: 35 mm (W) × 130 mm (H) × 100 mm (D)
Functional Features:
- 4 analog inputs and 4 analog outputs in one unit
- Selectable signal ranges (Voltage/Current) via switch
- High-resolution conversion (1/4000)
- Detachable terminal block
- Input disconnection detection
Application Scenarios:
- Process control requiring both sensing and actuation
- Compact machine automation
- Data acquisition and control
- PID control loops
Performance Parameters:
- Input Channels: 4
- Output Channels: 4
- Resolution: 12-bit (1/4000)
- Conversion Speed: 1 ms per point
Material Composition:
- Precision analog ICs
- Multi-layer printed circuit board
- Plastic housing
- Detachable terminal block
Structural Features: The unit features a compact 35mm width design. The front panel includes a detachable terminal block for field wiring and a voltage/current selection switch.
Working Principle: The unit receives analog signals from sensors, converts them to digital data for the CPU (Input), and receives digital data from the CPU to generate analog signals for actuators (Output).
Installation Requirements:
- Mount on CS1 series CPU rack or expansion rack.
- Connect field wiring to the detachable terminal block.
- Set the voltage/current switch according to the connected devices.
Usage Notes:
- Verify the signal range matches the connected devices.
- Ensure the unit is properly grounded to minimize noise interference.
- Do not exceed the maximum rated input voltage.
