Product Introduction: The NE2A-END is a termination resistor designed for use with OMRON’s NE2A safety network controller and DeviceNet communication networks. It is installed at the physical end of a DeviceNet trunk line to prevent signal reflections that can cause communication errors.

Request Quote
Category:

Description

OMRON NE2A-END

Technical Specifications:

  • Brand: OMRON
  • Model: NE2A-END
  • Product Type: DeviceNet End Resistor / Terminator
  • Compatible System: NE2A Series Safety Network Controller, DeviceNet networks
  • Resistance Value: 121Ω (standard DeviceNet termination)
  • Connection Type: DeviceNet compatible connector
  • Power Rating: Standard DeviceNet specification

Functional Features:

  • Terminates DeviceNet trunk lines to prevent signal reflection
  • Ensures reliable communication on safety networks
  • Plug-and-play installation at network endpoints
  • Compatible with NE2A safety controller systems

Application Scenarios:

  • DeviceNet safety network installations
  • NE2A safety controller network configurations
  • Industrial automation networks using DeviceNet protocol
  • Safety-critical communication systems

Performance Parameters:

  • Resistance: 121Ω
  • Protocol: DeviceNet
  • Connection: Standard DeviceNet connector

Material Composition:

  • Precision resistor element
  • Plastic housing
  • DeviceNet compatible connector

Structural Features: The NE2A-END is a compact, inline terminator that connects directly to the DeviceNet trunk line connector at the last node of the network. It is designed for easy installation without the need for additional tools.

Working Principle: In a DeviceNet network, signal reflections occur when electrical signals reach the end of a cable and bounce back, causing data corruption. The -END provides a 121Ω resistive termination that matches the characteristic impedance of the DeviceNet cable, absorbing the signal energy and preventing reflections.

Installation Requirements:

  • Install at the physical end of the DeviceNet trunk line
  • Ensure only one terminator is present at each end of the network
  • Connect using standard DeviceNet connectors
  • Verify network communication after installation

Usage Notes:

  • A DeviceNet network requires exactly two terminators (one at each end)
  • Do not install terminators at intermediate nodes
  • Verify the terminator is securely connected
  • Store in dry conditions
