Description
Telemecanique 9007CR61B2
Technical Specifications:
- Brand: Telemecanique Sensors
- Model: 9007CR61B2
- Voltage Rating: 600V
- Current Rating: 10A
- Mounting Style: Chassis Mount
Functional Features:
- Snap Action Mechanism: Provides fast, positive-make and positive-break contact operation for reliable switching.
- Heavy Duty Construction: Engineered to withstand harsh industrial conditions including dust, moisture, and mechanical shock.
- Versatile Actuation: Compatible with a wide range of lever arms and actuators for diverse application requirements.
Application Scenarios:
Widely used in steel mills, mining equipment, conveyor systems, and heavy machinery for travel limit detection and end-of-travel protection.
Performance Parameters:
- Electrical Life: High cycle life for repetitive switching operations.
- Mechanical Strength: Robust housing resists impact and vibration.
Material Composition:
Die-cast metal housing with silver-alloy contacts for superior conductivity and arc resistance.
Structural Features:
Compact NEMA enclosure with precision-machined actuator shaft. Features multiple conduit entry points and secure terminal connections.
Working Principle:
Mechanical force applied to the actuator compresses a spring mechanism that rapidly snaps the internal contacts between open and closed positions, providing precise position feedback.
Installation Requirements:
Mount securely to a rigid surface using appropriate hardware. Ensure the actuator operates within its specified travel range and force limits.
Usage Precautions:
Do not exceed the voltage or current ratings. Protect the switch from excessive heat, corrosive chemicals, and direct mechanical abuse.
