Description
Touch Screen 12-230-0851-I
Technical Specifications:
- Product Type: Industrial Touch Screen / HMI Panel
- Model: 12-230-0851-I
- Touch Technology: Resistive Touch Screen
- Display Type: Industrial TFT LCD
Functional Features:
- High Durability: Engineered with a reinforced front panel to resist impacts, scratches, and harsh industrial cleaning agents.
- Responsive Touch: Optimized resistive touch layer for accurate operation even when wearing industrial gloves.
- Wide Viewing Angle: Ensures clear visibility of process data from various operator positions.
- Easy Maintenance: Designed for straightforward touch screen film or digitizer glass replacement in the field.
Application Scenarios:
Ideal for factory automation, machine control panels, water treatment facilities, and any environment requiring a rugged operator interface.
Performance Parameters:
- Environmental Resistance: High resistance to electromagnetic interference (EMI), dust, and moisture.
- Operational Lifespan: Extended backlight and touch layer life for continuous 24/7 operation.
Material Composition:
Features a tempered or reinforced glass front overlay, industrial-grade LCD panel, and a robust metal or high-impact plastic rear housing.
Structural Characteristics:
Compact, bezel-less or narrow-bezel design for seamless panel integration. Includes standardized mounting brackets and industrial-grade rear connectors.
Working Principle:
The resistive touch layer detects physical pressure from a stylus or finger, converting the contact coordinates into digital signals that are processed by the HMI controller to execute corresponding machine commands.
Installation Requirements:
Ensure the control panel cutout dimensions match the specified requirements. Route communication and power cables away from high-voltage motor drives to prevent screen flickering or touch drift.
Usage Precautions:
Clean the screen only with approved, non-abrasive industrial cleaners. Avoid using sharp objects that could puncture the resistive touch film. If touch accuracy degrades, recalibrate via the HMI software or replace the touch digitizer glass.
