Description
Woodward 505XT8200-1311
Technical Specifications
- Platform: Woodward 505XT Enhanced Digital Control.
- Part Number: 8200-1311.
- Redundancy: Supports enhanced reliability and optional redundancy features.
Functional Features
- Expanded I/O: Additional analog and discrete channels compared to the standard 505D.
- Advanced Diagnostics: Enhanced self-monitoring, data logging, and predictive maintenance capabilities.
- Flexible Networking: Upgraded communication options including Ethernet and advanced Modbus TCP/IP support.
Application Scenarios
Ideal for modernizing large industrial steam turbines, high-pressure extraction turbines, and critical cogeneration plants requiring maximum uptime and advanced control strategies.
Performance Parameters
- Processing Speed: Faster scan rates for tighter control loops during transient conditions.
- Data Resolution: Higher resolution analog inputs for superior process variable accuracy.
Material Composition
Premium industrial components with enhanced thermal management and extended environmental ratings.
Structural Characteristics
- Form Factor: Compatible with standard 505 series mounting, though internal board layout is upgraded.
- User Interface: Enhanced display and navigation capabilities for easier commissioning.
Working Principle
Leverages advanced digital signal processing to execute complex multi-variable control algorithms, managing extraction pressures, inlet valves, and generator synchronization with unprecedented precision.
Installation Requirements
- Power Supply: Verify power requirements, as XT models may have different voltage tolerances.
- Network Setup: Configure advanced network parameters during initial commissioning.
Usage Precautions
- Firmware Management: Use only Woodward-approved software tools for parameter adjustments.
- Training: Operators and maintenance personnel should receive specific training on XT platform features.
