Product Introduction
The Woodward 5441-695C is a specific hardware revision (Revision C) of the 5441-695 digital processor card. It serves as the central processing unit for Woodward’s 544x series control platforms, offering enhanced processing capabilities, updated firmware compatibility, and improved reliability over previous revisions.

Request Quote
Category:

Description

Woodward 5441-695C

Technical Specifications

  • Product Series: 5441 Series Digital Control Processor.
  • Revision: C (Enhanced hardware/firmware compatibility).
  • Processor: High-speed 32-bit RISC processor.
  • Backplane: High-speed digital bus for communication with I/O and communication modules.

Functional Features

  • Real-Time Execution: Guarantees deterministic scan times for critical speed, load, and temperature control loops.
  • Advanced Protection: Processes safety-critical logic for overspeed, over-temperature, and vibration shutdowns.
  • Data Logging: Records operational trends and fault events for predictive maintenance.
  • Communication Gateway: Manages data exchange with SCADA, DCS, and local HMIs via multiple protocol options.

Application Scenarios
Core processing card in MicroNet, 5000 Series, or PeakMaster control systems for gas turbines, steam turbines, and large reciprocating engines.

Performance Parameters

  • Scan Rate: Basic control loop execution in under 10 milliseconds.
  • Mean Time Between Failures (MTBF): Exceeds 100,000 hours of continuous operation.

Material Composition
Multi-layer printed circuit board with surface-mount technology. Components are screened for extended industrial temperature ranges. Gold-plated edge connectors ensure reliable backplane contact.

Structural Characteristics
Standard form factor for the target Woodward chassis. Features front-panel LEDs for Run, Fault, and Communication status. Includes a local configuration port (USB or serial).

Working Principle
Continuously polls input modules for process variables, executes the user-defined control logic, and updates output modules. It operates on a deterministic real-time operating system to guarantee response times.

Installation Requirements
Verify the card’s address jumpers or DIP switches match the system configuration before insertion. Seat the card firmly into the backplane and secure the ejector levers.

Usage Precautions

  • Always observe electrostatic discharge (ESD) precautions when handling.
  • Never insert or remove the card while the chassis is powered.
  • Ensure firmware versions are compatible with other cards in the system.
