Description
Woodward 8237-1596
Technical Specifications
- Part Number: 8237-1596
- Protocols: Modbus TCP/IP and serial RTU
- Ports: Dual Ethernet and RS-485
- Data Rate: Up to 100 Mbps
Functional Features
- Dual Network: Redundant Ethernet ports for network failover.
- Data Logging: Stores trip events and system alarms with timestamps.
- Remote Access: Enables secure remote diagnostics and configuration.
Application Scenarios
Deployed in modern power plants and industrial facilities requiring comprehensive safety system visibility and integration.
Performance Parameters
- Latency: <10 ms for critical trip messages.
- Buffer Capacity: Stores up to 10,000 events.
Material Composition
Industrial Ethernet components with EMI shielding and surge protection.
Structural Characteristics
- Connectors: RJ-45 Ethernet and DB-9 serial ports.
- Status LEDs: Link activity, network status, and communication health.
Working Principle
Translates internal ProTech-SX data into standard industrial protocols. It continuously polls system modules and transmits updates to connected hosts while accepting configuration commands.
Installation Requirements
- Network: Connect to dedicated safety network VLAN.
- Cabling: Use Cat5e or better shielded Ethernet cable.
Usage Precautions
- Cybersecurity: Implement network segmentation and access controls.
- IP Configuration: Assign static IP addresses for reliable communication.
