Description
Woodward 9907-018 2301A
Technical Specifications:
- Brand: Woodward
- Model: 9907-018 2301A
- Product Type: Digital Speed/Load Controller
- Platform: 2301A Series
Functional Features:
- Multi-Mode Control: Supports isochronous, droop, and base load control modes for flexible operation.
- Advanced Protection: Integrates overspeed, underspeed, and comprehensive engine parameter monitoring.
- Load Sharing: Enables precise load distribution in multi-engine parallel operations.
Application Scenarios:
Widely used in diesel generator sets, gas engine generators, marine auxiliary engines, and industrial prime movers.
Performance Parameters:
- Speed Control Accuracy: Excellent steady-state speed regulation.
- Response Time: Fast dynamic response to load transients.
Material Composition:
Ruggedized industrial enclosure with conformal-coated internal electronics for extended service life in harsh environments.
Structural Features:
Features an integrated operator panel with LCD display and membrane keypad for local configuration, monitoring, and diagnostics.
Working Principle:
Samples engine speed and load signals, executes PID control algorithms, and adjusts fuel rack position to maintain precise speed and load setpoints under varying conditions.
Installation Requirements:
Mount securely in a control panel. Use shielded cables for speed sensor and actuator connections to prevent noise interference.
Usage Precautions:
Configure control parameters to match the specific engine and governor characteristics. Conduct thorough system testing before commercial operation.
