Description
Woodward EASYGEN-3500-5/P1
Technical Specifications
- Series: EasyGen 3500.
- Function: Generator protection, control, and monitoring.
- Protection: ANSI standard protection functions.
- Communication: Modbus, CAN bus.
Functional Features
- Integrated Protection: Over/under voltage, over/under frequency, overcurrent, reverse power, and loss of excitation.
- Generator Control: Auto-start, auto-sync, and load sharing.
- Monitoring: Real-time electrical and mechanical parameter display.
- Event Logging: Comprehensive event and fault recording for troubleshooting.
Application Scenarios
Used in commercial, industrial, and utility power generation systems requiring integrated protection and control.
Performance Parameters
- Protection Accuracy: High-precision measurement for reliable protection.
- Response Time: Fast tripping for fault clearance.
Material Composition
Industrial-grade electronic components in a robust enclosure.
Structural Characteristics
- Display: Graphical LCD with backlight.
- I/O: Extensive digital and analog inputs/outputs.
Working Principle
Continuously samples electrical parameters, compares them to protection setpoints, and executes control or tripping actions as required to protect the generator and connected equipment.
Installation Requirements
Connect CTs and VTs with correct polarity. Ensure proper grounding of the protection circuit.
Precautions for Use
Verify all protection settings are coordinated with the system. Perform primary injection testing to validate protection functions.
