Woodward PEAK-200
Technical Specifications
- Series: PEAK-200.
- Processing: High-speed microprocessor for real-time control.
- I/O Capacity: Extensive discrete and analog inputs/outputs.
- Communication: Industrial Ethernet, Modbus, and CANopen options.
Functional Features
- Advanced Governing: Isochronous and droop speed control with precise valve actuation.
- Safety Integration: Native support for overspeed protection and critical speed avoidance.
- Flexible Configuration: Customizable control algorithms for various turbine types.
- Diagnostics: Comprehensive self-diagnostics and trending capabilities.
Application Scenarios
Deployed in utility power generation, industrial cogeneration, and mechanical drive applications requiring high-reliability digital control.
Performance Parameters
- Control Accuracy: High-resolution speed and position control.
- Response Time: Millisecond-level processing for rapid load acceptance.
Material Composition
Industrial-grade electronics with conformal-coated printed circuit boards for enhanced environmental protection.
Structural Characteristics
Modular architecture allowing for scalable I/O and communication expansion.
Working Principle
Acquires real-time turbine parameters, executes sophisticated PID and sequential control logic, and outputs precise analog or discrete signals to steam valves and fuel actuators.
Installation Requirements
Install in a climate-controlled control panel. Ensure proper grounding and shielding of all sensor and communication cables.
Precautions for Use
Perform a full system checkout and safety trip test before placing the turbine into commercial service.
