Description
Woodward SPM-D108440-1019
Technical Specifications
- Part Number: 8440-1019.
- Type: Digital Protection Module.
- Communication: Digital interface for configuration and monitoring.
Functional Features
- Digital Precision: Eliminates analog drift and calibration issues.
- Event Logging: Records trip events and parameter history.
- Flexible Logic: Programmable trip delays and interlocks.
Application Scenarios
Used in modernized control systems requiring intelligent protection and diagnostic capabilities.
Performance Parameters
- Accuracy: High-resolution measurement.
- Diagnostics: Comprehensive self-testing.
Material Composition
Advanced microprocessor-based electronics with industrial-grade protection.
Structural Characteristics
Digital display or indicator panel for local status and parameter viewing.
Working Principle
Digitally samples input signals, executes protection algorithms, and provides both local indication and remote communication of system status.
Installation Requirements
Connect to the configuration software for initial setup. Ensure network connections are properly terminated.
Precautions for Use
Secure configuration parameters with passwords. Backup settings before performing maintenance.
