  • Product Introduction: This component is a specialized printed wiring assembly (PWA) memory board and control module designed for industrial automation systems. It serves as a critical internal hardware element within ABB’s distributed control systems (DCS) and programmable logic controller (PLC) frameworks, facilitating data storage, processing, and system communication.
Request Quote
Category: SKU: ABB 086318-002

Description

ABB 086318-002

  • Technical Specifications & Performance Parameters:
    • Output Frequency: Standard kHz range.
    • Operating Voltage: Standard industrial voltage specifications.
    • Speed Control Precision: Capable of achieving high-precision speed control with an accuracy of ±1 RPM.
    • Tracking Error: Minimal tracking error reaching ±1 Pulse.
    • Pulse Reception: Supports high-speed command modes with pulse reception up to 1 MHz.
    • Current Control Precision: ±25 mA.
    • Interpolation Synchronization: Precision within 2 ms.
  • Functional Features:
    • Supports multiple operational modes including pulse/direction, analog speed regulation, torque mode, and command position/speed/torque modes.
    • Features built-in configurable electronic gear functions.
    • Allows modification of encoder lines, motor angles, and motor pole pairs.
    • Enables seamless, instantaneous switching between various control modes.
    • Includes one high-current output port that can function as a brake output.
    • Provides comprehensive protection against undervoltage, overvoltage, overload, overcurrent, overtemperature, and encoder anomalies.
    • Supports alarm clearing via software and I/O ports.
  • Application Scenarios: Widely utilized in industrial automation, printing, packaging, electronic processing equipment, inkjet machines, channel gates, robotic grabbing machinery, specialized CNC machine tools, AGV vehicles, and robotics. Also applicable in communication networks, medical imaging, automotive electronics, energy management, and aerospace navigation systems.
  • Material Composition & Structural Characteristics: Constructed as a highly integrated industrial-grade circuit board module (PWA) featuring robust electronic components designed for high reliability and efficiency in demanding environments.
  • Installation Requirements & Usage Precautions: Must be handled with electrostatic discharge (ESD) precautions during installation. Ensure proper seating in the designated motherboard slot. Regular system diagnostics should be performed to monitor for temperature or voltage anomalies.
