Description
ABB 1KGT011900R0001
Technical Specifications
- Series: RTU560 Substation Automation
- Input Voltage Range: 24 V DC / 48 V DC (configuration dependent)
- Isolation Method: Optocoupler or transformer isolation
- Mounting: DIN rail mounting; fits RTU560 rack (typically 3U form factor)
- Operating Temperature Range: -25°C to +70°C
- Status Indication: LED indicators for power and operating status
- Redundancy Support: Supports redundant power input in selected configurations
Functional Features
- Distributes and couples input power to system modules
- Provides electrical isolation for improved noise immunity
- Offers grounding terminals for safety and compliance
- Real-time status LEDs for quick diagnostics
- Supports redundant power configurations to enhance availability
Application Scenarios
- Substation automation and RTU560 systems
- Power automation cabinets requiring robust power distribution
- Industrial control systems exposed to electrical noise
- Remote terminal units in harsh environments
Performance Parameters
- High reliability with wide operating temperature range
- Designed to maintain stable power distribution under electrical disturbances
- LEDs provide immediate visibility of operational state
Material and Structural Characteristics
- Industrial-grade enclosure suitable for control cabinet mounting
- Connector interfaces designed for RTU560 rack insertion
- Internal components arranged to ensure effective isolation and thermal performance
Working Principle
The unit takes the incoming DC supply, isolates it using optocouplers or transformer-based isolation, and distributes conditioned power to the RTU modules. It also provides grounding reference points, while status LEDs monitor input presence and correct operation.
Installation Requirements
- Mount onto DIN rail within an RTU560 rack or compatible cabinet
- Connect input supply wiring observing correct polarity
- Connect grounding terminals to the cabinet earth bar
- Ensure adequate clearance for ventilation and maintenance access
Usage Notes
- Verify input voltage configuration matches the field supply
- Periodically check LED status and terminal tightness
- Do not operate outside the specified temperature range
- Follow ABB RTU560 documentation for wiring and redundancy setup
