ABB REF615A_E HAFAABAAABE1BCA1XE
Technical Specifications:
- Product Line: Relion 615 Feeder Protection.
- Configuration: Custom I/O matrix based on the HAFAABAAABE1BCA1XE designation.
- Network Support: Seamless integration into IEC 61850 station and process buses.
Functional Features:
- Tailored I/O: Exact matching of hardware resources to the application’s control and interlocking needs.
- Standard Protection Suite: Overcurrent, earth fault, and breaker failure protection.
- Interlocking: Extensive programmable logic for busbar and switchgear interlocking.
Application Scenarios:
- Custom-built Medium Voltage (MV) switchgear.
- Specialized distribution automation panels.
- Retrofit projects requiring exact hardware matching.
Material Composition & Structural Characteristics:
- Modularity: Scalable hardware architecture allowing precise resource allocation.
- Connectors: High-density, vibration-resistant terminal blocks.
Working Principle:
Operates identically to the standard REF615 platform, executing protection and control logic based on the specific I/O and functional parameters defined by the custom order code.
Installation Requirements:
- Strictly adhere to the specific wiring diagram associated with the HAFAABAAABE1BCA1XE order code.
- Validate all binary input and output assignments during the FAT (Factory Acceptance Test) or SAT (Site Acceptance Test).
Usage Precautions:
- Cross-reference the exact order code with ABB documentation to confirm available hardware resources.
- Do not attempt to utilize unassigned I/O channels in the protection logic.
