ABB 3BHB043805R0001
Technical Specifications:
| Parameter | Value |
|---|---|
| Product Model | 3BHB043805R0001 |
| Manufacturer | ABB |
| Product Category | Industrial Automation Module / PLC Module |
| Input Voltage Range | 24 V DC (±10%) |
| Power Supply | 24 V DC bus voltage |
| Operating Current | Bus current ≤3 mA; Power supply current ≤20 mA |
| Monitoring Current | Bus current ≤1 mA; Power supply current ≤5 mA |
| Dimensions | 132 mm × 105 mm × 52 mm |
| Weight | Approximately 0.5 kg |
| Protection Rating | IP20 (standard) / IP30 |
| Operating Temperature | -10°C to +70°C (standard); -40°C to +85°C (extended option) |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting | DIN rail or panel-mounted |
| Wire System | Non-polar signal two-bus connection with controller; non-polar power supply two-bus connection with DC24V power supply |
| Output Control Mode | Pulse, level (relay normally open contact output or active output; pulse start relay suction time is 10s) |
| Passive Output Contact Capacity | DC24V/2A; normal contact resistance value is 100 kΩ |
Functional Features:
- Robust Communication Capabilities: Supports industry-standard protocols such as Profibus DP, Modbus, and other fieldbus systems, ensuring interoperability with diverse devices and subsystems. Facilitates real-time data exchange between controllers, sensors, actuators, and higher-level systems such as SCADA.
- High Reliability and Redundancy: Engineered for mission-critical environments, offering fault-tolerant operation and optional redundancy configurations to minimize downtime.
- Modular Design: Compatible with ABB’s AC 800M platform, allowing flexible expansion of I/O and communication interfaces via modular slots. Hot-swappable capability for easy maintenance without system shutdown.
- Advanced Diagnostics: Built-in self-diagnostic functions and status indicators (LEDs) for rapid troubleshooting and preventive maintenance.
- Electromagnetic Compatibility: Compliant with IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-8, and IEC 61000-4-11 standards.
Application Scenarios:
- Power generation and distribution grid automation
- Oil and gas process control in upstream and downstream operations
- Water and wastewater treatment pump control and monitoring systems
- Manufacturing robotics and production line automation
- Substation automation for grid stability and fault isolation
Material and Structure:
- Constructed with industrial-grade materials featuring a compact form factor
- DIN rail-mountable design for space-efficient installation in control cabinets
- Conformal coating option available for enhanced durability in corrosive or high-humidity environments
Installation Requirements:
- Install in clean environments free of interference
- Ensure proper grounding and shielding for EMC compliance
- Use anti-static wrist straps during installation to prevent electrostatic discharge damage
