ABB 3BHE024747R0101
Technical Specifications:
| Parameter | Value |
|---|---|
| Product Model | 3BHE024747R0101 |
| Manufacturer | ABB |
| Product Category | Crowbar Board / PC Board / High Voltage Control Board |
| Product Origin | USA / Switzerland |
| Weight | 0.67 kg to 1.37 lbs (approximately 1.0 kg shipping weight) |
| Input Voltage | 220 V |
| Power Supply Voltage | 24 V DC |
| Power Consumption | <5 W |
| Output Frequency | 30 kHz |
| Input Channels | 8 channels (digital) |
| Output Channels | 16 channels (relay output) |
| Maximum Load Current | 2 A |
| Communication Protocol | RS-485 |
| Baud Rate | 9600 bps, 19200 bps, 38400 bps, 57600 bps |
| Dimensions | Compact PCB form factor |
| Status | Discontinued by manufacturer |
Functional Features:
- Overvoltage Protection: Crowbar circuit design provides rapid short-circuit protection against overvoltage conditions in drive systems.
- High-Voltage Equipment Control: Controls circuit breakers, disconnect switches, and other high-voltage equipment in medium-voltage switchgear.
- High Precision: Uses high-precision electronic components to ensure control accuracy.
- High Reliability: Industrial-grade design with strong anti-interference capability and wide working temperature range.
- Easy Integration: Standard terminals provided for user-friendly connection.
Application Scenarios:
- Power generation plants
- Electrical substations
- Industrial factories
- Mining operations
- Oil and gas pipelines
- Railway systems
- Marine and shipboard applications
Material and Structure:
- High-quality printed circuit board with robust copper traces
- Industrial-grade electronic components
- Compact design for integration into control cabinets
Working Principle: The crowbar board monitors system voltage levels and rapidly triggers a short-circuit path (crowbar action) when dangerous overvoltage conditions are detected, thereby protecting sensitive downstream equipment from damage.
Important Note: This product has been discontinued by ABB. Replacement parts or alternative solutions are required for ongoing system maintenance. Factory warranty may no longer apply.
