Description
ABB 87TS50-ER1414 GKWE857800R1414
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Communication Coupling Module |
| Input Voltage | 24V DC |
| Operating Temperature | 0°C to +60°C |
| Ethernet Interface | 10BaseT (RJ-45) |
| System Bus | Station bus interface |
| Mounting Style | Rack mount for Procontrol P14 system |
| Weight | 3 kg |
| Lead Time | 4-6 weeks (typical) |
Functional Features
- Ethernet Connectivity: 10BaseT RJ-45 interface enables connection to plant management systems, engineering workstations, and external networks.
- Station Bus Interface: Seamless integration with the Procontrol P14 station bus for real-time data exchange with process controllers.
- MMI System Connection: Designed specifically for connecting Man-Machine Interface systems to the Procontrol P14 control network.
- High-Speed Data Transfer: Supports deterministic data communication required for real-time process control applications.
- Robust Industrial Design: Engineered for reliable operation in power plant and industrial control room environments.
- Modular Architecture: Hot-swappable design allows replacement without system shutdown, minimizing maintenance impact.
Application Scenarios
- Power Plant Automation: Interface between Procontrol P14 process stations and plant management systems for supervisory control.
- SCADA Integration: Gateway module for connecting ABB control systems to SCADA networks and enterprise-level systems.
- Engineering Access: Remote access point for engineering tools including KISS and PDDS configuration software.
- System Expansion: Communication bridge for integrating additional process stations or external control systems into existing P14 networks.
- HMI Connectivity: Direct connection to operator workstations and process graphics displays.
Installation Requirements
- Install in Procontrol P14 system rack with proper grounding.
- Connect Ethernet cable with shielded twisted-pair cabling (Category 5 or higher).
- Ensure proper termination of station bus connections.
- Configure network parameters via ABB engineering tools before commissioning.
Operating Precautions
- Verify Ethernet cable integrity and shield grounding before system startup.
- Monitor communication status LEDs for link activity and fault detection.
- Do not disconnect the module during active data transmission to prevent communication errors.
- Perform periodic inspection of connector integrity and cable condition.
