Product Overview:
The ABB AO801 is a standard analog output module belonging to the S800 I/O series. It is specifically designed for use with AC800M controllers and the 800xA distributed control system. This module provides eight independent analog output channels, converting digital control signals from the system into precise analog signals to drive field actuators and process control devices.

Request Quote
Category: SKU: ABB AO801

Description

ABB AO801

Technical Specifications:

  • Output Channels: 8 independent analog output channels.
  • Signal Type: 0/4-20 mA current output.
  • System Compatibility: S800 I/O series, AC800M controller, 800xA system.
  • Resolution: High-resolution digital-to-analog conversion.
  • Power Supply: Operates via the S800 I/O bus power.

Functional Features:

  • Independent Channel Configuration: Each of the 8 channels can be individually configured, scaled, and calibrated.
  • Fault Detection: Built-in diagnostic capabilities to detect open circuits, short circuits, and wire breaks.
  • Fail-Safe Mode: Programmable fail-safe states (e.g., hold last value, output 0 mA, or output 20 mA) in case of communication loss or module failure.
  • High Precision: Ensures accurate and stable signal transmission for precise process control.

Application Scenarios:

  • Control of control valves and dampers in power generation and petrochemical plants.
  • Speed reference and torque control for variable frequency drives (VFDs).
  • Positioning control in industrial manufacturing and material handling.
  • General process control requiring continuous analog actuation.

Performance Parameters:

  • Accuracy: Typically ±0.1% of the full-scale range.
  • Temperature Drift: Low drift characteristics to maintain accuracy across varying industrial temperatures.
  • Update Rate: Fast cyclic update time synchronized with the controller’s task rate.
  • Load Impedance: Supports standard industrial loop impedances (typically up to 500Ω or higher depending on supply voltage).

Material Composition & Structural Characteristics:

  • Enclosure: Standard S800 I/O module housing with integrated terminal blocks.
  • Circuit Board: Multi-layer printed circuit board (PCB) with conformal coating for protection against moisture and corrosion.
  • Connectors: Robust screw-type or spring-clamp terminal blocks for secure field wiring.
  • Indicators: Front-panel LEDs for module status, channel activity, and fault indication.

Working Principle:
The module receives digital setpoint values from the AC800M controller over the internal I/O bus. An onboard digital-to-analog converter (DAC) translates these digital values into precise analog current signals. The output stage amplifies and regulates the current to drive the connected field device, while continuous feedback monitoring ensures the actual output matches the commanded value.
