Product Introduction:
The ABB CI570 is an Ethernet communication adapter for the S800 I/O system, enabling high-speed TCP/IP-based industrial networking. It bridges the gap between traditional field I/O and modern Ethernet-based control architectures.

Request Quote
Category: SKU: ABB CI570 3BSE001440R1

Description

ABB CI570 3BSE001440R1

Technical Specifications:

  • Network Type: Industrial Ethernet (Modbus TCP, EtherNet/IP).
  • Interfaces: Dual RJ45 ports with integrated switch.
  • Order Code: 3BSE001440R1.

Functional Features:

  • Integrated Switch: Eliminates the need for external Ethernet switches by supporting daisy-chain topology.
  • High Bandwidth: Supports rapid data exchange for large I/O configurations.
  • Web-Based Diagnostics: Built-in web server for remote IP configuration and network troubleshooting.

Application Scenarios:

  • Modernizing legacy fieldbus networks to Ethernet.
  • High-density I/O applications requiring fast data refresh rates.

Performance Parameters:

  • Latency: Ultra-low network latency for real-time control.
  • Throughput: 10/100 Mbps auto-negotiation.

Material Composition & Structural Features:

  • Enclosure: Rugged industrial housing with LED indicators for link and activity status.

Working Principle:
Encapsulates S800 I/O process data into standard Ethernet TCP/IP or UDP frames, routing them through the integrated switch to the upstream controller.

Installation Requirements:

  • Connect using CAT5e or higher industrial-grade Ethernet cables.
  • Configure IP addresses and subnet masks via DIP switches or software tools.

Usage Precautions:

  • Avoid connecting to non-industrial office networks to prevent broadcast storms.
  • Ensure proper strain relief on Ethernet cables.
