ABB CI810B 3BSE020520R1
ABB CI810B 3BSE020520R1 - Image 2

ABB CI810B 3BSE020520R1

Product Introduction:
The ABB CI810B is a core communication interface module for the ABB S800 I/O system. It serves as the base coupler and protocol gateway, linking the S800 I/O bus to the master controller’s fieldbus adapter.

Request Quote
Category: SKU: ABB CI810B 3BSE020520R1

Description

ABB CI810B 3BSE020520R1

Technical Specifications:

  • Bus Type: S800 I/O internal bus.
  • Compatibility: Works with CI85x, CI86x, and CI87x communication adapters.
  • Order Code: 3BSE020520R1.

Functional Features:

  • I/O Bus Management: Distributes power and data to all attached S800 I/O modules.
  • Redundancy Support: Compatible with redundant communication setups for high availability.
  • Hot-Swapping: Supports module replacement without powering down the bus.

Application Scenarios:

  • Foundation module for building distributed I/O stations.
  • Critical process applications requiring fault-tolerant communication.

Performance Parameters:

  • Backplane Speed: High-speed serial backplane communication.
  • Power Distribution: Regulated 24V DC backplane power.

Material Composition & Structural Features:

  • Connectors: Precision backplane connectors with gold-plated contacts.

Working Principle:
Receives high-level fieldbus commands from the communication adapter and translates them into S800 I/O bus protocols for local module access.

Installation Requirements:

  • Mount on a standard 35mm DIN rail.
  • Connect to the communication adapter using the dedicated S800 bus connector.

Usage Precautions:

  • Ensure the total backplane current draw does not exceed the CI810B’s rated capacity.
  • Install terminating resistors at the end of the I/O bus.
