Product Introduction:
The ABB CM592-DP is a dedicated PROFIBUS DP communication module designed for ABB AC drives, particularly the ACS800 and ACS880 series. It enables drives to communicate as PROFIBUS DP slaves, receiving speed/torque references and sending status feedback directly from the PLC.

Request Quote
Category: SKU: ABB CM592-DP

Description

ABB CM592-DP

Technical Specifications:

  • Protocol: PROFIBUS DP-V0/V1.
  • Max Baud Rate: 12 Mbps.
  • Compatibility: ACS800, ACS880 series drives.

Functional Features:

  • Direct Drive Integration: Maps drive parameters directly to PROFIBUS process data.
  • Flexible PPO Types: Supports multiple PPO (Process Data Object) types for varying data volumes.
  • Diagnostics: Comprehensive drive and bus fault reporting via PROFIBUS.

Application Scenarios:

  • Multi-drive coordinated motion control.
  • Centralized monitoring and control of pump/fan arrays.
  • Integration with Siemens S7 PLCs in process industries.

Performance Parameters:

  • Response Time: Deterministic cyclic data exchange.
  • Data Mapping: Configurable parameter mapping via drive software.

Material Composition & Structural Features:

  • Form Factor: Plug-in module for drive control board slot.
  • Connectors: DB9 female connector for PROFIBUS bus.

Working Principle:
Intercepts PROFIBUS telegrams and translates them into drive control words and reference values, while packaging drive status words for the master PLC.

Installation Requirements:

  • Insert into the designated communication slot on the drive control board.
  • Connect PROFIBUS cable with proper termination.

Usage Precautions:

  • Configure PPO type and parameter mapping in the drive’s PROFIBUS menu.
  • Ensure the drive’s PROFIBUS station address matches the PLC configuration.
