The NPBA series are communication option boards​ for the Advant OCS / MasterPiece 200 / Advant Controller 450 family. The NPBA-12 typically provides:

  • 2 × Serial Ports (Configurable per port as RS-232 or RS-485):
    • Port A: Often RS-485 (Modbus RTU Master to drives/slaves, or Slave to DCS)
Request Quote
Category: SKU: ABB NPBA-12

Description

ABB NPBA-12

  • Technical Specifications (typical NPBA-12 for Advant 450):
    • Mounting: Controller communication slot (Advant 450 — left-side slots; MasterPiece 200 — COM slot)
    • Serial Ports: 2 (Port A & B)
      • Port A: RS-485 (half-duplex, opto-isolated ≥500 V), screw terminals or DB9 (model dep.) — Modbus RTU Master/Slave up to 19.2 / 38.4 / 57.6 / 115.2 kbps
      • Port B: RS-232 (D-sub 9 female) — for local service PC or SattBus to ABB drive (RDCO-04 with SattBus)
    • Protocols: Modbus RTU (Master & Slave), SattBus (ABB drive link), ASCII (some FW versions)
    • Max Slaves (Modbus Master): Typically 32 per port (practical ≤16 for scan time)
    • Indicators: Run (green), Err (red), Tx/Rx LEDs per port
    • Power: From controller backplane (5 V DC)
    • Operating Temp.: 0 °C to +55 °C
    • Firmware: Loaded from controller CPU; configured in Advant / Control Builder project (define NPBA station → assign protocol & port params → download)
    • Certifications: CE, UL, cUL
  • Functional Features / Application / Material / Structure / Working Principle / Installation / Precautions:
    • Used to connect Advant 450 to:
      • ABB ACS600/800 drives via SattBus (Port B RS-232 → RDCO-04 SattBus) for parameter read/write & start/stop
      • Plant DCS / SCADA via Modbus RTU (Port A RS-485 — Advant as Slave reporting process values, or as Master polling remote I/O)
      • Legacy serial printers / logger (Port B)
    • In Advant Eng Tool: add “NPBA-12” station → set port A = Modbus Slave (Node addr, baud, parity), Port B = SattBus (drive node addrs) → define I/O mapping (Modbus registers ↔ controller variables)
    • Precaution:​ RS-485 A/B polarity critical — reversed → no comm; terminate bus ends with 120 Ω if >50 m or per Modbus spec. For SattBus to drives: max total cable length & node count per SattBus spec (typically ≤500 m, ≤31 nodes). Keep NPBA firmware version compatible with controller CPU firmware — check ABB compatibility matrix before upgrade.
    • If NPBA-12 is listed alongside NPCT-01C & NPOW-62C​ (below) → these are the complete Advant 450 communication & power set: NPCT-01C = time sync / ComBus Terminator, NPOW-62C = 24 V DC PSU for Advant rack, NPBA-12 = serial Com board.
