Description
ABB REF615C-C HCFFAEAGANB2BAN1XC
Technical Specifications:
- Model: REF615C-C
- Order Code: HCFFAEAGANB2BAN1XC
- Type: Numerical Feeder Protection Relay
Functional Features:
- Customized Functionality: Tailored hardware and software configuration based on the specific order code.
- Advanced Logging: High-capacity event and disturbance recording for detailed post-fault analysis.
- Seamless Integration: Pre-configured communication settings for rapid deployment in existing substations.
Application Scenarios:
Deployed in critical infrastructure, mining operations, and large industrial facilities requiring customized protection solutions.
Performance Parameters:
- Accuracy Class: Meets stringent IEC standards for protection and metering accuracy.
- Environmental Rating: Suitable for operation in demanding industrial environments.
Material Composition:
High-quality, flame-retardant materials with gold-plated contacts for reliable signal transmission.
Structural Features:
Standard 19-inch rack or panel-mount form factor with clearly labeled terminals and intuitive front-panel indicators.
Working Principle:
Operates as a standalone intelligent electronic device (IED), executing protection logic locally while providing comprehensive data to the substation automation system.
Installation Requirements:
Strictly adhere to the wiring diagram corresponding to the specific order code. Ensure all communication and grounding connections are secure.
Usage Precautions:
Consult the specific technical manual for the HCFFAEAGANB2BAN1XC order code to verify exact functionality. Always use approved test equipment for secondary injection.
