ABB REM543
ABB REM543 - Image 2

ABB REM543

Product Overview:
The ABB REM543 is a comprehensive protection relay designed primarily for small and medium-power diesel, hydroelectric, and steam power plants. It serves as the main protection system for generators and generator-transformer units, while also providing extensive protection for large and medium-voltage synchronous and asynchronous motors during start-up and normal operation.

Request Quote
Category: SKU: ABB REM543

Description

ABB REM543

Technical Specifications:

  • Protection Scope: Selective short-circuit and earth-fault protection specifically tailored for rotating machines.
  • I/O Configuration: Features 15 binary inputs and 12 output relays.
  • Communication: Supports IEC 61850 protocol through the SPA-ZC 400 adapter and offers optical communication for fast, disturbance-free data transfer.
  • Measurement: Compatible with conventional measuring transformers, current sensors, and voltage dividers.

Functional Features:

  • Abnormal Condition Protection: Protects against over-current, unbalanced load, over-temperature, over-voltage, over/under-excitation, under-impedance, over/under-frequency, and generator motoring.
  • Motor Supervision: Includes stall protection and a cumulative start-up counter for motor start-up supervision.
  • Programmable Logic: Integrated Programmable Logic Controller (PLC) functions for customized control strategies.
  • Certifications: Certified for marine and off-shore use, ensuring reliability in harsh environments.

Application Scenarios:

  • Main protection for generators in small and medium power plants.
  • Protection of large MV synchronous/asynchronous motors in pumps, mills, and crushers.
  • Marine and off-shore power generation facilities.

Material Composition & Structural Characteristics:

  • Hardware Design: Robust industrial terminal design with flexible connectivity options.
  • Optional Modules: Supports optional RTD (Resistance Temperature Detector) inputs for direct temperature monitoring.

Working Principle:
The REM543 continuously samples voltage and current signals, processing them through advanced algorithms to detect electrical faults and abnormal operating conditions. Upon detecting a predefined anomaly, it triggers the corresponding output relays to isolate the faulted equipment, safeguarding the rotating machine.

Installation Requirements:

  • Ensure proper connection of conventional measuring transformers or current sensors.
  • Integrate the SPA-ZC 400 adapter if IEC 61850 communication is required.
  • Route optical communication cables separately from high-voltage power lines to maintain signal integrity.

Usage Precautions:

  • Note that the REM543 has been an inactive product since 2022; plan for lifecycle management or upgrades.
  • Regularly verify the cumulative start-up counter and thermal models to prevent motor degradation.
