Description
ABB REX521GHHGSH05G
Technical Specifications:
- Order Code: REX521GHHGSH05G
- Function: Bay/System Controller and Automation Hub
- Platform: ABB Relion 600 Series
Functional Features:
- Interlocking Logic: Executes complex switching interlocks to prevent unsafe operational sequences.
- Data Concentration: Aggregates data from multiple protection relays and IEDs for efficient SCADA communication.
- Sequence Control: Automates complex switching operations with built-in safety checks.
Application Scenarios:
Medium and high-voltage substations, renewable energy collection stations, and industrial power distribution networks.
Performance Parameters:
- Processing Speed: Fast execution of logic and communication tasks.
- Scalability: Supports extensive I/O and communication expansion.
Material Composition:
Industrial-grade electronics housed in a shielded, rack-mountable enclosure.
Structural Features:
Standard 19-inch rack form factor with multiple Ethernet and serial communication ports.
Working Principle:
Receives status data from field IEDs, evaluates it against predefined interlocking and automation logic, and issues control commands or forwards data to the station level.
Installation Requirements:
Install in a climate-controlled control room rack. Connect to redundant station bus networks for high availability.
Usage Precautions:
Thoroughly test all interlocking logic in a simulated environment before deploying to a live substation. Maintain strict cybersecurity practices for network-connected controllers.
