Product Overview:
The ABB TU840 is a standard termination base unit for the S800 I/O platform, providing field connections for a wide range of digital and analog modules. It is a fundamental component in building distributed I/O systems with reliable and maintainable field wiring.

Request Quote
Category: SKU: ABB TU840

Description

ABB TU840

Technical Specifications:

  • Compatibility: Universal S800 I/O module support.
  • Terminal Type: Spring-clamp for fast wiring.
  • Power: 24V DC field power distribution.
  • Shield Connection: Integrated shield clamp.

Functional Features:

  • Universal Compatibility: Works with most S800 I/O modules.
  • Hot-Swap: Enables maintenance without system shutdown.
  • Clear Labeling: Integrated label strip for organization.
  • Test Points: Accessible for field diagnostics.

Application Scenarios:

  • General-purpose I/O in industrial automation.
  • Distributed control in large-scale plants.
  • Retrofit and modernization projects.

Material Composition & Structural Characteristics:

  • Housing: Durable plastic with DIN rail mount.
  • Terminals: Reliable spring-clamp connections.
  • Connectors: Precision mating surface for I/O modules.

Working Principle:
Provides the physical and electrical interface between field wiring and the S800 I/O module. Field wires terminate on the base unit, and the module plugs in to establish connections for power, signals, and diagnostics.

Installation Requirements:

  • Mount on DIN rail in a ventilated enclosure.
  • Use appropriate wire ferrules for spring-clamp terminals.
  • Attach cable shield to the shield clamp.

Usage Precautions:

  • Ensure the module is fully seated and locked.
  • Do not exceed terminal ratings.
