Product Introduction:
The ABB YPC104B YT204001-BT is a robust FSK (Frequency Shift Keying) modem board engineered specifically for industrial communication systems. It is designed to ensure reliable and efficient data transmission, even in harsh environments subject to electromagnetic interference. This module facilitates seamless long-distance communication and integrates perfectly with ABB controllers and automation systems such as the Advant OCS and 800xA series.

Request Quote
Category: SKU: ABB YPC104B YT204001-BT

Description

ABB YPC104B YT204001-BT

Technical Specifications:

  • Brand: ABB
  • Model: YPC104B YT204001-BT
  • Product Type: Industrial FSK Modem Board
  • Modulation Method: Frequency Shift Keying (FSK)
  • Communication Protocol: FSK-based serial communication
  • Power Supply: 24 VDC
  • Protection Rating: IP20
  • Dimensions: 12.7 cm × 5.1 cm × 20.3 cm
  • Weight: 0.2 kg
  • Country of Origin: Sweden/Germany

Functional Features:

  • Reliable Data Transmission: Engineered to maintain signal integrity in environments with high electromagnetic interference.
  • Broad Compatibility: Works seamlessly with ABB TYRAK L, CONTRAC L, and other ABB automation systems.
  • Flexible Mounting: Supports both DIN rail and panel mounting configurations for versatile installation.
  • Long-Distance Communication: Optimized for extending industrial networks over extended physical distances.

Application Scenarios:

  • Industrial automation and control systems.
  • Remote monitoring and data acquisition networks.
  • Legacy system upgrades within ABB Advant OCS architectures.

Performance Parameters:

  • Signal Stability: High noise immunity due to FSK modulation.
  • Integration Speed: Plug-and-play compatibility with supported ABB controllers.

Material Composition & Structural Features:

  • Industrial Enclosure: Compact, ruggedized board layout designed for continuous industrial operation.
  • Mounting Hardware: Equipped with standard industrial DIN rail clips and panel mounting holes.

Working Principle:
The module utilizes Frequency Shift Keying (FSK) to encode digital data into analog carrier frequencies. This allows serial data to be transmitted reliably over long distances via standard cabling, converting the signals back to digital data at the receiving end without loss of integrity.

Installation Requirements:

  • Mount securely on a standard DIN rail or flat panel using appropriate hardware.
  • Connect to a stable 24 VDC power supply.
  • Ensure communication cables are properly shielded and routed away from high-voltage power lines.

Usage Precautions:

  • Always disconnect power before installing or removing the modem board.
  • Verify that the connected ABB controller firmware supports this specific modem model.
  • Maintain operating temperatures within the specified IP20 industrial range.
