Description
Bently 106M1079-0
Technical Specifications
- Part Number: 106M1079-01
- Module Type: 3500/15 Universal AC Power Supply
- Input Frequency: 47 to 63 Hz
- System Compatibility: Bently Nevada 3500 Series
Key Features
- High Reliability: Utilizes solid-state switching technology for long life and low failure rates.
- Wide Input Tolerance: Accommodates severe voltage fluctuations common in industrial power grids.
- Hot-Swappable: Can be safely removed and replaced while the framework remains fully operational.
- Integrated Diagnostics: Provides real-time power health data to the System 1 software.
Application Scenarios
Deployed globally in critical infrastructure to power TSI (Turbine Supervisory Instrumentation) racks for steam turbines, gas compressors, and large industrial motors.
Performance Parameters
- Power Output: Sufficient to drive a fully populated 3500 framework
- Efficiency: High-efficiency power conversion minimizing heat generation
Material Composition
Heavy-duty industrial enclosure with internal conformal coating to protect against moisture, dust, and corrosive atmospheres.
Structural Characteristics
Half-height form factor designed for the left-side framework slots. Features a secure locking mechanism and standardized backplane connectors.
Working Principle
Acts as an intelligent power hub. It converts AC to DC, distributes power across the backplane, and reports internal temperature and voltage levels to the system’s communication modules for predictive maintenance.
Installation Requirements
Install in the designated left-side slots. If configuring a redundant power system, ensure both power supplies are of the same universal type.
Usage Precautions
Ensure the external AC breaker is appropriately sized for the module’s input current. Never force the module into the slot; align carefully to prevent backplane pin damage.
