Description
Bently 3300/05-25-00-00
Technical Specifications
- Product Series: 3300 Series Rack Frame
- Part Number: 3300/05-25-00-00
- Mounting Type: Panel Mount / Standard Rack Mount
- System Compatibility: 3300 Monitor Modules
Functional Features
- Modular Architecture: Provides multiple slots for inserting different monitor modules (e.g., vibration, displacement, temperature) to build a customized protection system.
- Backplane Connectivity: Integrates internal bus wiring for seamless power distribution and data communication between modules.
- Grounding and Shielding: Offers a robust metallic enclosure to protect sensitive electronic components from external electromagnetic interference.
Application Scenarios
Deployed in control rooms and local junction boxes across power plants, refineries, and chemical facilities to house and organize critical machinery protection hardware.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Environmental Protection: IP20 (when installed in a standard control cabinet)
- Electrical Isolation: High dielectric strength between power and signal buses
Material Composition
Heavy-duty industrial steel chassis, powder-coated for corrosion resistance, and high-quality copper backplane traces.
Structural Characteristics
A rigid rectangular metal frame featuring front-facing module guides, rear terminal strip access, and standardized DIN rail or panel mounting holes.
Working Principle
Acts as a passive electrical distribution and mechanical support system, routing DC power and inter-module signals through the backplane to all installed monitor cards.
Installation Requirements
Secure the frame firmly to a flat panel or standard 19-inch rack using appropriate hardware. Ensure adequate clearance for rear wiring and module extraction.
Usage Precautions
Always verify that the backplane is free of debris before inserting modules. Ground the frame securely to the plant earth to prevent ground loops and signal noise.
