Description
Bently 3300 16-11-01-03-00-00-01
Technical Specifications
- Model: 3300 16-11-01-03-00-00-01
- Channels: 2 independent vibration inputs
- Relay Outputs: Programmable alert and danger relays
- Analog Outputs: Buffered 4-20 mA outputs
Functional Features
- Multi-Sensor Compatibility: Software-configurable to accept 2-wire or 3-wire accelerometers, velocity sensors, or eddy current probes.
- Local Display: Features a front-panel display for real-time viewing of vibration values and alarm status.
- Flexible Configuration: Parameters are defined via PC software and downloaded via the built-in communication interface.
Application Scenarios
Extensively used in power plants, chemical facilities, and steel mills to protect auxiliary equipment such as fans, compressors, water pumps, and motors.
Performance Parameters
- Display: Real-time vibration value display
- Configuration Storage: Non-volatile memory retains settings during power loss
Material Composition
Housed in a robust, industrial-grade enclosure designed for panel mounting, providing excellent EMI shielding and mechanical protection.
Structural Characteristics
Compact standalone module with front-panel LED status indicators, local display, and rear terminal blocks for sensor and relay wiring.
Working Principle
Receives analog signals from vibration sensors, conditions the signals, converts them to digital values, and compares them against user-defined alarm thresholds to trigger relays or analog outputs.
Installation Requirements
Mount in a standard control panel. Connect sensors using shielded cables and ensure proper grounding to prevent electrical noise interference.
Precautions for Use
Configuration parameters must be defined using Bently Nevada configuration software. Verify sensor type and sensitivity settings match the installed field devices.
