Description
Bently 3300/16-12-01-02-00-00-00
Technical Specifications
- Product Series: 3300 Vibration Monitoring System
- Part Number: 3300/16-12-01-02-00-00-00
- Channel Configuration: Dual Channel
- Input Type: Proximity Probe (Eddy Current)
- Configuration Variant: “-02-00” specific parameters
Functional Features
- Variant Configuration: Offers modified parameters compared to the base 3300/16-12-01-01 model, addressing specific application needs.
- Dual Channel Monitoring: Maintains full dual-channel functionality for comprehensive vibration assessment.
- Proven Reliability: Built on the industry-standard 3300/16 platform, ensuring consistent performance and longevity.
Application Scenarios
Suitable for a wide range of rotating machinery where the specific “-02-00” configuration aligns with the machinery protection requirements or control system integration needs.
Performance Parameters
- Measurement Range: 0 to 500 µm (0 to 20 mils) Peak-to-Peak
- Frequency Response: 10 Hz to 10 kHz
- Accuracy: ±1% of full scale
- Output Signal: 4-20 mA and relay outputs per “-02-00” specification
Material Composition
Rugged steel chassis with high-quality electronic components, designed for continuous operation in harsh industrial environments.
Structural Characteristics
Standard 3300 rack module with front-panel indicators and test points. The specific suffix indicates internal configuration differences.
Working Principle
Utilizes standard eddy current signal demodulation, with parameters adjusted to meet the specific requirements of this part number variant.
Installation Requirements
Install in a properly grounded 3300 series rack. Follow standard wiring practices and refer to specific documentation for this variant.
Usage Notes
Verify the exact configuration of this “-02-00” variant before installation. Alarm setpoints and output scaling may differ from other 3300/16 modules.
