Bently 330101-00-08-05-02-00
Technical Specifications
- Product Series: 3300 XL 8mm Proximity Probe
- Part Number: 330101-00-08-05-02-00
- Probe Diameter: 8 mm
- Thread Type: 3/8-24 UNF
- Unthreaded Length: 0.0 inches
- Overall Case Length: 0.8 inches
- Total Cable Length: 0.5 meters (1.6 feet)
- Connector Type: Miniature coaxial ClickLoc connector, standard cable
- Agency Approval: Not required
Functional Features
- Non-Contact Measurement: Provides precise measurement of both static position and dynamic vibration without physical contact with the rotating shaft.
- High Sensitivity: Delivers 7.87 V/mm (200 mV/mil) output for accurate detection of minute vibration changes.
- API 670 Compliance: Meets the stringent requirements of API 670 for mechanical configuration, linear range, accuracy, and temperature stability.
- System Interchangeability: Fully interchangeable with other 3300 XL 8mm proximity probes without individual matching.
Application Scenarios
Widely deployed in fluid film bearing machines for radial vibration monitoring, axial displacement measurement, Keyphasor reference, and speed measurement. Common applications include steam turbines, gas turbines, centrifugal compressors, pumps, fans, and gearboxes.
Performance Parameters
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 2 mm (80 mils)
- Frequency Response: 0 to 10 kHz
- Accuracy: ±1% of full scale
- Operating Temperature: -40°C to +177°C (standard probe)
- Recommended Gap Setting: 1.27 mm (50 mils)
Material Composition
Stainless steel probe body with precision-wound internal coil, TipLoc patented molding technology for secure tip-to-body connection, and CableLoc patented design rated for 330 N (75 lbs) tensile strength.
Structural Characteristics
Cylindrical 8mm diameter probe with 3/8-24 UNF mounting thread. The probe features an integrated short cable (0.5 meters) terminated with a miniature coaxial ClickLoc connector for connection to the extension cable. The non-armored construction provides flexibility for installation in confined spaces.
Working Principle
The probe contains a precision coil that generates a high-frequency alternating magnetic field when energized by the Proximitor. When a conductive target surface (shaft) enters this field, eddy currents are induced in the target, creating an opposing magnetic field that alters the probe coil’s impedance. This impedance change is proportional to the gap distance between the probe tip and the target surface.
Installation Requirements
Mount the probe using the 3/8-24 UNF thread in a tapped hole on the machine bearing housing. Ensure the probe tip is perpendicular to the target surface. The total system electrical length (probe cable + extension cable) must match the Proximitor rating. Use ClickLoc connectors for secure, tool-free connection.
