Description
Bently 330104‑05‑10‑10‑02‑CN
- Key Features: 8 mm standard probe tip; M10×1 metric mounting thread; stainless‑steel flexible armor over integral cable; TipLoc hermetic tip sealing; CableLoc high‑strength cable‑probe junction; full component interchangeability within 3300‑XL product family; stable linear measurement output under wide temperature variation; CN marking for local acceptance documentation.
- Technical Specifications & Performance Parameters
- Probe tip diameter: 8 mm
- Integral armored cable length: 1.0 m
- Linear measuring range: 0‑2.14 mm
- Nominal sensitivity: 7.87 V/mm
- Probe body operating temperature: ‑51 ℃ ~ +177 ℃
- Cable operating temperature: ‑51 ℃ ~ +177 ℃
- Storage temperature: ‑55 ℃ ~ +180 ℃
- Frequency response: 0‑12 kHz
- Thread specification: M10×1‑6g metric external thread
- Weight: 0.56 kg
- Maximum tensile resistance: 330 N
- Material Composition: AISI 304 stainless‑steel probe housing and threaded mounting body; precision‑wound copper sensing coil; PPS probe‑tip material; FEP triaxial insulated inner cable; AISI 302 stainless‑steel armor braid; gold‑plated brass Mini‑Dot connector; high‑temperature epoxy sealing resin.
- Structural Features: Compact cylindrical probe body with M10×1 external mounting thread; TipLoc molded sealed sensing tip; rear‑exit armored integral cable; Mini‑Dot termination connector; CableLoc reinforced cable‑housing transition structure; fully sealed internal coil chamber to block oil mist and moisture penetration.
- Working Principle: Proximitor outputs high‑frequency excitation signal delivered via triaxial armored cable to probe internal coil. Eddy‑current effect generates on metallic shaft‑target surface. Coil impedance changes with physical gap variation. Proximitor converts impedance fluctuation into proportional DC gap‑voltage and AC vibration analog‑output signal for monitoring equipment racks.
- Application Scenarios: Petrochemical compressor shaft‑vibration and thrust‑position monitoring; power‑plant turbine supervisory instrumentation; field sites with high mechanical‑abrasion risk for sensor cables; spare‑part replacement for existing CN‑certified 3300‑XL installations; rotating‑machinery retrofitting projects.
- Installation Requirements: Install probe into precision‑machined mounting bracket; tune initial gap within linear working‑range; fully lock Mini‑Dot connector locking ring; separate armored sensor cable routing away from high‑voltage power‑cable trays; implement single‑point grounding for cable shielding layers; verify total system cable length matches proximitor factory‑calibration requirement.
- Usage Notes: Prevent collision and scratch damage to probe sensing tip; strictly follow minimum bending‑radius requirement for armored cable assembly; forbid cutting or field‑splicing integral probe cable; keep Mini‑Dot connector gold contacts free of grease, dust and moisture; inspect armor for dents and connector tightness during regular equipment overhaul.
