Description
Bently 330130-045-00-05
Technical Specifications
- Product Series: 3300 XL 8mm Eddy Current Sensor System
- Cable Length: 4.5 meters (14.8 feet)
- Connector Type: Standard Micro-Coaxial ClickLoc
- System Compliance: API 670 Standard
Functional Features
- Extended Reach: Tailored for applications requiring longer system lengths without signal degradation.
- Non-Contacting Measurement Support: Ensures reliable signal transmission for non-contacting shaft motion sensors.
- Robust Immunity: Resistant to EMI/RFI, ensuring reliable data transmission in electrically noisy environments.
Application Scenarios
Ideal for large-scale rotating equipment where the monitoring cabinet is situated at a significant distance from the machinery bearings.
Performance Parameters
- Operating Temperature Range: -52°C to +177°C (-62°F to +350°F)
- Capacitance: Precisely matched to the probe and proximitor for accurate signal transmission
- Shielding: Multi-layer shielding for superior EMI/RFI immunity
Material Composition
Constructed with high-temperature FEP insulation and a braided stainless steel shield, providing excellent resistance to heat, chemicals, and mechanical stress.
Structural Characteristics
Features a flexible, oil-resistant jacket with integrated strain relief at both ends. The ClickLoc connectors are gold-plated for optimal conductivity and corrosion resistance.
Working Principle
Acts as a passive transmission line, carrying the high-frequency signal from the probe to the proximitor without altering the signal’s characteristics.
Installation Requirements
Route the cable away from high-voltage power lines and sources of electromagnetic interference. Maintain the minimum bend radius to prevent internal conductor damage.
Usage Precautions
Never bend the cable beyond its specified minimum bend radius. Inspect the connectors regularly for signs of corrosion, damage, or loosening.
