Bently 330130‑045‑12‑05
Technical Specifications: Cable Length: 4.5 m Nominal Impedance: 75 Ω Cable Construction: FluidLoc triaxial coaxial structure, non‑armored Operating Temperature Range: ‑51 °C ~ +177 °C Minimum Static Bend Radius: 25.4 mm Connector Type: Click‑Loc gold‑plated FluidLoc explosion‑proof self‑locking coaxial connector with external connector protector Agency Certifications: ATEX, IECEx, CSA intrinsically‑safe approvals Maximum Tensile Load: 330 N Capacitance: 69.9 pF/m Net Weight: 360 g Compatible System: 3300 XL 8 mm proximity transducer system
Functional Features: FluidLoc‑reinforced‑sealing‑structure‑blocks‑oil‑mist‑and‑liquid‑medium‑penetration‑towards‑connector‑internal‑contact‑cavity.‑Hard‑connector‑protector‑shell‑protects‑connector‑parts‑against‑external‑impact‑‑scratch‑‑and‑knock‑damage.‑Explosion‑proof‑certified‑Click‑Loc‑self‑locking‑connector‑prevents‑vibration‑caused‑disconnection‑‑tool‑free‑assembly‑and‑disassembly.‑Full‑triaxial‑shielding‑suppresses‑industrial‑EMI‑RFI‑electromagnetic‑interference.‑Dual‑end‑CableLoc‑strain‑relief‑structures‑disperse‑tensile‑stress‑‑prevent‑inner‑conductor‑breakage.‑Factory‑pre‑calibrated‑electrical‑matching‑removes‑requirement‑for‑field‑recalibration.‑FEP‑outer‑jacket‑maintains‑stable‑performance‑under‑oil‑mist‑‑dust‑‑and‑corrosive‑atmosphere‑in‑hazardous‑locations.‑Meets‑intrinsically‑safe‑installation‑specifications‑for‑explosive‑gas‑zones.
Application Scenarios: Signal‑transmission‑for‑shaft‑vibration‑‑axial‑displacement‑‑and‑Keyphasor‑phase‑reference‑measurement‑of‑turbines‑‑centrifugal‑compressors‑‑gear‑boxes‑‑and‑process‑pumps‑in‑petrochemical‑‑refinery‑‑and‑coal‑chemical‑hazardous‑classified‑areas‑with‑heavy‑oil‑mist‑environment‑and‑connector‑anti‑collision‑requirements.
Performance Parameters: Center Conductor DC Resistance: 0.99 Ω ±0.12 Ω Shield Conductor DC Resistance: 0.30 Ω ±0.08 Ω Connector Mating Cycle Life: More than 1000 insert‑extract cycles Maximum Operating Relative Humidity: 93 % non‑condensing
Material Composition: Inner Insulation Layer: Fluoroethylene‑Propylene (FEP) Signal Conductor: High‑purity silver‑plated copper Outer Jacket: FEP fluoropolymer Connector Body: Gold‑plated brass alloy with explosion‑proof structural qualification FluidLoc Sealing Component: Reinforced fluororubber composite material for hazardous‑area service Connector Protector Shell: High‑strength glass‑filled PPS engineering plastic
Structural Features: 75‑Ω‑FluidLoc‑structure‑triaxial‑soft‑cable‑without‑stainless‑steel‑armor‑layer.‑Both‑cable‑ends‑are‑equipped‑with‑ATEX‑IECEx‑CSA‑qualified‑Click‑Loc‑FluidLoc‑explosion‑proof‑self‑locking‑connectors‑‑each‑connector‑is‑fitted‑with‑detachable‑hard‑plastic‑protector‑shell.‑CableLoc‑strain‑relief‑transition‑sections‑molded‑at‑two‑cable‑terminals.‑Whole‑cable‑assembly‑is‑integrally‑manufactured‑‑no‑intermediate‑splice‑joints‑exist‑inside‑cable‑body.
