Description
Bently 330130-080-00-00
Technical Specifications
- Model: 330130-080-00-00
- Sensor Type: Eddy Current Proximity Probe
- Cable Length: 8.0 meters
- System Compatibility: 3300 XL Series
Functional Features
- Extended Reach: Accommodates installations where the proximitors must be located far from the sensor mounting point.
- High-Fidelity Transmission: Maintains precise impedance-to-voltage conversion across the extended cable length.
- Robust Assembly: Integrates the probe, cable, and connector into a single, sealed unit for maximum reliability.
Application Scenarios
Used in large turbines, generators, and specialized machinery where control cabinets or junction boxes are situated at a significant distance from the bearing housings.
Performance Parameters
- Sensitivity: Matched to standard 3300 XL specifications
- Operating Temperature: Rated for continuous industrial operation
- Linearity: High-precision linear output across the designated measurement range
Material Composition
High-temperature polymer tip encapsulation, precision copper coil, and specialized shielding cable designed for long-distance signal transmission.
Structural Characteristics
Custom-length integrated cable assembly with precision-machined probe body and specialized connector termination.
Working Principle
Functions on the standard eddy current principle, converting the physical gap between the probe and the metallic target into a proportional electrical signal.
Installation Requirements
Follow the specific mechanical drawing and gap voltage specifications associated with this exact part number. Proper torque and thread sealant application are critical.
Precautions for Use
Due to the extended cable length, ensure the cable is properly routed and secured to prevent mechanical damage. Verify the system sensitivity matches the probe specification. Inspect for oil ingress at the connector.
