Bently 330180-90-01

Description

Bently 330180-90-01

Technical Specifications

Key Features

• Traditional Panel Mount: Features standard 8mm mounting holes for traditional screw mounting to panels or enclosures
• CSA/NRTL/C Certification: Approved for use in Class I, Division 2 hazardous locations, meeting North American safety standards
• High RF Immunity: Highly immune to radio frequency interference, simplifying installation in electrically noisy environments
• Electrical Isolation: Panel mount base is electrically isolating, eliminating the need for separate insulating boards
• Full System Interchangeability: All 3300 XL 8mm components are fully interchangeable without individual matching
• API 670 Compliance: Complete system meets API 670 Standard (4th Edition) requirements
• Backward Compatibility: Compatible with non-XL 3300 series 5mm and 8mm components

Application Scenarios

• Petrochemical plant machinery monitoring: Certified for use in hazardous areas with flammable gases and vapors
• Oil refinery rotating equipment: Monitors critical compressors, pumps, and turbines in explosion-risk environments
• Natural gas processing: Measures shaft vibration and position in gas compressors and expanders
• Chemical plant critical equipment: Monitors agitators, reactors, and process pumps in hazardous locations
• Offshore platform equipment: Certified for marine hazardous area installations
• Power generation in hazardous areas: Monitors equipment in coal handling, fuel oil systems, and hydrogen-cooled generators
• Pharmaceutical manufacturing: Meets safety requirements for solvent-handling equipment monitoring

Performance Parameters The Proximitor provides identical electrical performance to other 3300 XL 8mm Proximitors. The linear output range is 2.0 mm (80 mils) with linearity of ±0.025 mm (±1.0 mil). The incremental scale factor is 7.87 V/mm (200 mV/mil) with ±0.25 V/mm tolerance. The average scale factor is within ±1.0%. The frequency response is 0 to 10 kHz (-3dB). The CSA/NRTL/C certification ensures safe operation in specified hazardous environments without compromising measurement performance.

Material Composition The Proximitor enclosure is constructed from aluminum with anodized finish. The panel mount base is made from electrically insulating composite material certified for hazardous location use. Internal electronic components include precision operational amplifiers, RF demodulation circuits, and filtering networks. The PCB is FR-4 epoxy glass fiber with industrial-grade components. Connectors are gold-plated brass. The unit is fully encapsulated with materials rated for the specified temperature range.

Structural Characteristics The Proximitor features a rectangular enclosure with standard 8mm diameter mounting holes on the panel mount base for screw attachment. The RF input connector and signal output connector are located on opposite ends. The enclosure includes grounding provisions for hazardous location installation. Internal layout separates RF and signal processing stages. The unit is fully potted for environmental and vibration protection. CSA/NRTL/C approval labels are affixed to the enclosure.

Working Principle The working principle is identical to other 3300 XL 8mm Proximitors. The unit receives the modulated RF signal from the probe via extension cable, demodulates it using precision detector circuitry, filters and amplifies the resulting signal, and produces a DC voltage output proportional to the probe-to-target gap. The output is -10.0 VDC at the recommended 0.25mm (10 mils) mounting gap. The CSA/NRTL/C certification ensures that all electrical energy levels are limited to safe values for the specified hazardous environment.

Installation Requirements

• Must be installed in accordance with CSA/NRTL/C Class I, Division 2 wiring methods and practices
• Mount on a grounded metal panel in a suitable enclosure rated for the hazardous location
• Ensure proper electrical isolation from ground using the insulating panel mount base
• Use sealed conduit or cable glands for all cable entries into the hazardous area enclosure
• Connect the probe/extension cable to the RF input connector with proper torque
• Connect output to the monitoring system using shielded cable with shield grounded at the safe area end
• Connect -24 VDC power supply observing correct polarity
• Install external barrier or isolator if required by local electrical codes for intrinsically safe circuits
• Maintain all hazardous location certification labels and markings
• Follow all applicable national electrical codes for Division 2 installations
