Description
Bently 330709-000-040-10-02-00
Technical Specifications
| Parameter Category | Specific Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Family | 3300 XL 11mm Proximity Transducer System |
| Thread Specification | M16 x 1.5 metric thread |
| Unthreaded Length | 000 = 0.0 mm (no unthreaded section) |
| Overall Case Length | 040 = 40.0 mm |
| Total Cable Length | 10 = 1.0 meter (3.3 feet) |
| Cable Option | 02 = Non-armored (standard) |
| Agency Approval | 00 = No agency approval required |
| Probe Diameter | 11.0 mm |
| Linear Range | 4.0 mm (160 mils) |
| Sensitivity | 3.94 V/mm (100 mV/mil) with system |
| Target Material | Calibrated for AISI 4140 steel |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel |
| Operating Temperature (Probe) | -51°C to +177°C (-60°F to +350°F) |
| Storage Temperature | -51°C to +260°C (-60°F to +500°F) |
| Pressure Sealing | Viton O-ring standard |
| DC Resistance | 5.9 ± 0.5 ohms (for 1.0m cable) |
| Typical Capacitance | 69.9 pF/meter |
| Weight | Approximately 0.15 kg |
Key Features
- M16x1.5 Metric Thread: Larger metric thread for heavy-duty European machinery
- 40mm Case Length: Substantial case length for secure mounting
- 0mm Unthreaded Length: Full thread to tip design
- 11mm Diameter with 4mm Range: Large linear range
- TipLoc and CableLoc Technology: Strong mechanical bonds
- ClickLoc Connector: Reliable connection
- Full System Interchangeability: Interchangeable within 3300 XL 11mm system
Application Scenarios
- Heavy European machinery: Monitors shaft vibration in large European-designed equipment
- Large turbine bearings: Measures shaft position in large steam and gas turbines
- Heavy compressor monitoring: Monitors shaft vibration in large process compressors
- Large generator bearings: Measures air gap and shaft vibration in large generators
- Rolling mill equipment: Monitors roll position in heavy rolling mills
- Large pump monitoring: Measures impeller position in large pumps
- Wind turbine monitoring: Monitors main bearing condition in large wind turbines
- Marine propulsion: Measures shaft vibration in large marine propulsion systems
Performance Parameters Identical to other 3300 XL 11mm probes.
Material Composition Identical to other 3300 XL 11mm probes.
Structural Characteristics Cylindrical stainless steel case with M16x1.5 external thread. The 0mm unthreaded length means the thread extends to the probe tip. The 40mm overall case length provides substantial thread engagement. The integral cable exits from the rear. The probe tip is molded PPS with flat sensing face.
