Description
Bently 330876-02-10-00-00
Technical Specifications
- Cable Type: 3300 XL Extension Cable
- Length: 10.0 meters (32.8 feet)
- Configuration: 02-10-00-00
- Connectors: Standard ClickLoc
Functional Features
- Extended Reach: Allows the Proximitor to be mounted in a safe, accessible location away from extreme heat or vibration.
- Signal Integrity: Precision coaxial geometry maintains consistent impedance and prevents signal attenuation.
- EMI Shielding: Provides excellent protection against electromagnetic interference in electrically noisy environments.
Application Scenarios
Essential for installations where the monitoring electronics must be located far from the machinery, such as in outdoor environments or distant control rooms.
Performance Parameters
- Capacitance: Matched to 3300 XL system requirements
- Operating Temperature: -51°C to +177°C
- Impedance: 50 Ohms nominal
Material Composition
Inner PTFE dielectric, braided copper shield, and outer protective jacket.
Structural Characteristics
Flexible coaxial cable with ClickLoc connectors on both ends for seamless connection between the probe and transducer.
Working Principle
Serves as a passive transmission line, carrying the high-frequency RF signal from the probe to the transducer without altering the signal characteristics.
Installation Requirements
Route the cable away from high-voltage power lines to prevent induced noise. Secure the cable with appropriate clamps to prevent vibration-induced fatigue.
Usage Precautions
Do not kink or bend the cable beyond its minimum bend radius. Inspect the connectors regularly for signs of corrosion or physical damage.
