Description
Bently 330877-080-36-00
Technical Specifications
- Cable Type: 3300 XL Armored Extension Cable
- Length: 8.0 meters (26.2 feet)
- Construction: Armored
- Connectors: Standard ClickLoc
Functional Features
- Mechanical Protection: The armored sheath shields the internal signal conductors from crushing, abrasion, and rodent damage.
- Harsh Environment Rated: Ideal for outdoor installations or areas with high ambient temperatures and chemical exposure.
- Signal Integrity: Precision coaxial geometry maintains consistent impedance over the 8.0-meter distance.
Application Scenarios
Widely applied in steel, power, metallurgy, and petrochemical industries where cables are exposed to severe mechanical hazards.
Performance Parameters
- Capacitance: Matched to 3300 XL system requirements
- Operating Temperature: -51°C to +177°C (standard armored)
- Impedance: 50 Ohms nominal
Material Composition
Inner PTFE dielectric, braided copper shield, and outer stainless steel or galvanized steel armor jacket.
Structural Characteristics
Flexible yet rugged coaxial cable with ClickLoc connectors on both ends.
Working Principle
Serves as a passive transmission line, carrying the high-frequency RF signal from the probe to the transducer without altering the signal characteristics.
Installation Requirements
Route the cable away from high-voltage power lines. Secure the cable with appropriate clamps to prevent vibration-induced fatigue.
Usage Precautions
Do not kink or bend the cable beyond its minimum bend radius. Inspect the armor regularly for signs of corrosion or physical damage.
